S urge Arrester, metal-oxide arrester limits the voltage across the insulation to a value below the insulator flashover voltage. Therefore, the lightning surge current is diverted to ground in a controlled manner and the insulation is left intact. The system works for direct lightning strokes to phase conductors and for backflash attributed to poor grounding and capacitive coupling.

ARRESTERS

Surge Arrester, metal-oxide arrester limits the voltage across the insulation to a value below the insulator flashover voltage. Therefore, the lightning surge current is diverted to ground in a controlled manner and the insulation is left intact. The system works for direct lightning strokes to phase conductors and for backflash attributed to poor grounding and capacitive coupling.

Categories: ARRESTERS

ARRESTERS

Product No.	Description	LIGHTENING IMPULSE	SPECS	Add Qty to Cart
MPH5W-3	Lightening Arrester	MPH5W-3	kV(crest) 9 A(crest) 150	ADD
MPH5W-6	Lightening Arrester	MPH5W-6	kV(crest) 18 A(crest) 150	ADD
MPH5W-9	Lightening Arrester	MPH5W-9	kV(crest) 28 A(crest) 150	ADD
MPH5W-10	Lightening Arrester	MPH5W-10	kV(crest) 30 A(crest) 150	ADD
MPH5W-11	Lightening Arrester	MPH5W-11	kV(crest) 33 A(crest) 150	ADD
MPH5W-12	Lightening Arrester	MPH5W-12	kV(crest) 36 A(crest) 150	ADD
MPH5W-15	Lightening Arrester	MPH5W-15	kV(crest) 45 A(crest) 150	ADD
MPH5W-18	Lightening Arrester	MPH5W-18	kV(crest) 54 A(crest) 150	ADD
MPH5W-21	Lightening Arrester	MPH5W-21	kV(crest) 63 A(crest) 150	ADD
MPH5W-24	Lightening Arrester	MPH5W-24	kV(crest) 72 A(crest) 150	ADD
MPH5W-27	Lightening Arrester	MPH5W-27	kV(crest) 81 A(crest) 150	ADD
MPH5W-30	Lightening Arrester	MPH5W-30	kV(crest) 90 A(crest) 150	ADD
MPH5W-33	Lightening Arrester	MPH5W-33	kV(crest) 99 A(crest) 150	ADD
MPH5W-36	Lightening Arrester	MPH5W-36	kV(crest) 108 A(crest) 150	ADD
